FOXEER Arrow Micro Pro
Производитель
Foxeer
Категория
Камеры аналог
Размеры камеры
19mm
Частота
2.4GHz
| Solution | Sony 1/3″ CCD Sensor + Nextchip 2040 DSP |
| Pixel | PAL: 976*494; NTSC: 768*494 |
| Tv System | PAL/NTSC(Optional) |
| Resolution | 600YVL(Color) 650TVL(B&W) |
| Synchronization | Internal |
| Video Output | CVBS Analog Signal |
| FOV | 1.8mm FOV: 160°2.1mm FOV: 135° |
| Shutter Speed | Auto |
| Minimum Illumination | 0.01Lux |
| WDR | DWDR 90dB |
| DNR | 2D DNR |
| OSD Programming Board | Support |
| DAY/NIGHT | EXT/Auto/Color/B&W |
| Flight OSD | Name Voltage Time |
| Input Voltage | 5V~40V |
| Power Consumption | 75mA/12V 166mA/5V |
| Working Temperature | -10°~50°C RH90% MAX |
| Working Humidity | 20~80% |
| Storage Temperature | -20°~70°C |
| Dimension | 19*19mm |
| Weight | 5.3g(Exclude cable) |
